BBM33L extra PQ6

Core drilling machine, rig mounted- over 3,0 kW

  • Powerful core drilling machine, for extreme requirements
  • Rotor is hand- wound, for maximum filling degree of copper. More copper means more power and better constancy of temperature, consequently better efficiency factor
  • hydraulic, magnetic protection switch (if triggering due to overload, machine can be started directely)
  • Gear protection via mechanical clutch
  • 3 speed gear in oil bath with circulating oil pump
  • Water connection mountable in different positions
  • Mounted carrying strap with soft hand grip for ergonomical transport handling

Technical datas BBM33Lextra PQ6
Power input 3300W
Power output 2775 W
Voltage/ Frequency 50-60 Hz
Rated speed min-1 180/ 430/ 750
Rated torque Nm 125/ 59/ 33
Drilling range mm 45- 450
Drill bit connection PQ6
Dimensions mm 509× 168× 142
Weight 13,2 kg
Hole pattern for mounting Standard
(4xM8, Key Slot 10×5mm)
Order Number 200664
