| Technical datas | EBL33 | EBL33L |
| Power input | 2500W | 2500W |
| Power output | 1950 | 1950 |
| Voltage/ Frequency | 230V/ 50-60 Hz | 230V/ 50-60 Hz |
| Rated speed min-1 | 450/ 1200/ 2500 | 300/520/ 1700 |
| Rated torque Nm | 36/ 19/ 10 | 55/ 19/ 10 |
| Drilling range mm | 15- 160mm | 20- 250 mm |
| Drill bit connection | 1 ¼” UNC + R½“ | 1 ¼” UNC + R½“ |
| Collar | Ø 60mm | Ø 60mm |
| Dimensions mm | 422×100×295 | 562×100×150 |
| Weight | 6,5kg | 6,5kg |
| Hole pattern for mounting | Standard (4xM8, Key Slot 10×5mm) | Standard (4xM8, Key Slot 10×5mm) |
| Order Number | 200964 | 201193 |
